Two doors in series must have a minimum of 48 in addition to the width of the doors swinging into the space so a 36 door swinging into a hall would require the hall to be a minimum of 7 0 long before any other door could be placed if the second door does not also swing into the hall. Doorways should be at least 32 inches wide with the door open at 90 degrees.
Fig 25 Maneuvering Clearances At Doors
Door swing and other space requirements doors can swing into the turning space.
Ada door swing. Doors with closers should take at least 5 seconds to move from the open position at 90 degrees to 12 degrees from the latch. If a standard stall is provided at the end of a row of stalls and if the length of the stall is extended at least a minimum of 36 inches 915 mm beyond the required minimum length the door if located on the side of the stall diagonal to the water closet may swing into the stall. Hallways and walkways should provide at least 80 inches of clear head room he says.
Closing times for automatic doors vary depending on the type of door swinging. Ada clear doorway widths. The closing or swing speed must not be faster than five seconds.
For example the handle shown below requires the user to tightly grasp the handle to open the door. Current guidelines for bathrooms published in 2010 allow the bathroom door to swing inward as long as there is a clear floor space. 4138 thresholds at doorways.
This allows users to clear one door or gate before opening the next and applies to those doors or gates that are opposite each other where travel through both doors is required. Also state or local government codes may have specific accessibility requirements for exterior doors. Any door so heavy that it prevents entrance by people with disabilities may deny them access to goods and services which is covered under the ada.
The turning space can overlap other space requirements including clear floor space required at elements and fixtures. Inaccessible door hardware can also prevent access to the business. At hinged or pivoted doors or gates in series a separation is required that is at least 48 plus the width of doors or gates swinging into the space.
There are many other ways to make your restrooms and the areas around them more accessible and to ensure ada compliance spear points out. Like any building code ada guidelines are subject to change. It may also be possible to use special swing clear hinges that provide approximately 1 12 inches more clearance without replacing the door and door frame.
Doors with spring hinges should take at least 15 seconds to close from the open position of 70 degrees. Doors in series shall swing either in the same direction or away from the space between the doors. Thresholds at doorways shall not exceed 34 in 19 mm in height for exterior sliding doors or 12 in 13 mm for other types of doors.
